HD 4MP Wifi 4G IP Network Camera Smart Outdoor IP PTZ Network Solar Battery Camera
- Model：IPCM0315
Feature APP: Ubox
Image Sensor: 1/3" CMOS Sensor
Lens: 3.6mm
Resolution: 4MP
IR-CUT filter: Switch automatically
Night Vision: IR Light / Colorful
Two-way Audio: Supported
Connection way: 2.4Ghz WiFi or 4G Sim-card
Wireless Standard: 2.4GHz, 802 .11b/g/n (5G is not supported)
Storage: Cloud storage(extra charge) / SD Card(optional)
Color: Korea Gray
Power Consumption: <10W Packing Included: 1* Solar Camera (included battery)
1* Solar Panel
1* 5m extension cable
1* Set of Screw
1* User Manual
Product Paramenters
|
project
|
product description
|
|
|
product name
|
Solar Battery Powered Floodlight PTZ Camera
|
|
|
Comprehensive
|
Master chip
|
T31ZL
|
|
APP operating system
|
Android, IOS
|
|
|
sensor
|
1/3″ Image Sensor
|
|
|
Compression format
|
H.264+/H.265
|
|
|
Pixel
|
4MP
|
|
|
APP
|
UBOX
|
|
|
Networking method
|
4G
|
TD-LTE, TD-LTE / LTE FDD TD-LTE / LTE-FDD (Full Netcom)
|
|
Alarm mode
|
Detection mode
|
PIR
|
|
Detection distance
|
0~12M
|
|
|
Detection angle
|
120°
|
|
|
Alarm method
|
Double induction confirmation push alarm message to mobile phone
|
|
|
PTZ
|
PTZ angle
|
Horizontal 355° vertical 90°
|
|
Rotating speed
|
Horizontal 55°/sec Vertical 40°/sec
|
|
|
Night Vision Mode
|
Full color night vision
|
Illumination 0.00001LUX
|
|
Infrared light
|
Infrared LED distance 20M
|
|
|
White light
|
White LED distance 10M
|
|
|
sound
|
Built-in speaker
|
1W
|
|
Built-in microphone
|
Monitoring range 20M
|
|
|
Lens
|
focal length
|
3.6mm
|
|
angle
|
85°
|
|
|
storage
|
Cloud storage
|
Cloud storage (alarm recording)
|
|
Local storage
|
TF card (max 128G)
|
|
|
power supply
|
Power supply mode
|
Solar +21700 battery
|
|
Solar cell power
|
5W
|
|
|
battery capacity
|
built in 3PCS 21700 batteries (3*4000MA=12000MA)
|
|
|
Maximum working power
|
4W
|
|
|
Standby power
|
0.003W
|
|
|
other
|
working environment
|
Indoor/outdoor
|
|
Operating temperature
|
-30°~+60°
|
|
|
Working humidity
|
0%~90%RH
|
|
|
package
|
net weight
|
1.66KG/PCS
|
|
Color box size
|
245*190*137mm
|
|
|
Qty
|
12pcs
|
|
|
Gross weight
|
20KG/CTN
|
|
|
Carton size
|
50*40*42CM
|
|
|
Core selling point
|
1，Yard lighting/Red and blue lights are combined with audible and visual alarms and low power consumption Pioneer
|
|
|
2， Built-in battery
|
||
|
3，Small size, save freight
|
||
|
4，Easy to install (can be integrated/split installation）
|
||
